Caterpillar
Komatsu
PC130-6
Excavator
48 specifications
1 / 5
Image 1 of 5
Specifications
34 data points
Engine
| Engine Model | Cat C4.4 ACERT with Twin Turbo |
|---|---|
| Displacement | 269 in³ |
| Net Power | 150.0 hp |
| Stroke | 5 in |
| Bore | 4 in |
| Emissions | Meets Tier 4 Final/Stage IV emission standards. |
| Maximum Torque - 1,400 rpm | 523 lb-ft |
| Ratings | 1,800 rpm |
| Note | *Metric values. |
| Engine Power - Maximum Net - ISO 9249/SAE J1349 | 150.2 hp |
| Engine Power - Maximum Gross - ISO 14396 | 156.9 hp |
Weights
| Counterweight | 8,267 lb |
|---|
Hydraulic System
| Maximum Flow - Auxiliary Circuit - Medium Pressure | 12.7 gal/min |
|---|---|
| Maximum Pressure - Auxiliary Circuit - High Pressure | 5,076 psi |
| Maximum Pressure - Implement Circuit - Heavy Lift | 5,439 psi |
| System | 64.7 gal |
| Maximum Flow - Implement/Travel Circuit | 58.0 gal/min |
| Maximum Pressure - Auxiliary Circuit - Medium Pressure | 2,683 psi |
| Maximum Flow - Auxiliary Circuit - High Pressure | 58.0 gal/min |
| Maximum Flow - Swing Mechanism | 18.5 gal/min |
| Maximum Pressure - Implement Circuit - Normal and Travel Circuit | 5,076 psi |
| Swing Mechanism | 4,786 psi |
Transmission
| Drawbar Pull | 23,380 lb |
|---|---|
| Maximum Forward/Reverse - 2nd Gear | 19.0 mph |
Undercarriage
| Ground Clearance | 16 in |
|---|
General Specifications
| Net Power | 150.00 hp (111.86 kw) Starting 2021 Model Year |
|---|---|
| Operating Weight | 36,972.00 lbs (16,770.24 kg) Starting 2021 Model Year |
| Engine | C4.4 ACERT Starting 2021 Model Year |
| Max Travel Speed | 19.00 mph (30.58 kph) Starting 2021 Model Year |
Drive System
| Maximum Travel Speed | 19.0 mph |
|---|
Service Refill Capacities
| Diesel Exhaust Fluid Tank | 5.0 gal |
|---|---|
| Fuel Tank - Total Capacity | 77.9 gal |
Swing Mechanism
| Swing Speed | 8 rpm |
|---|---|
| Maximum Swing Torque | 327,468 in |
