Komatsu

PC210LC-6 MIGHTY

Excavator

Operating Weight
49,340 lb
Max Digging Depth
261 in
Net Power
132.8 hp
All excavators
Komatsu PC210LC-6 MIGHTY Excavator
1 / 5
Image 1 of 5
Image: exapro.com

Specifications

28 data points

Operating Specifications

Operating Specifications specifications
Operating Weight49,340 lb
Fuel Capacity89.9 gal
Hydraulic Pump Flow Capacity108.9 gal/min
Hydraulic System Fluid Capacity43.9 gal
Hydraulic System Relief Valve Pressure5,050 psi

Engine

Engine specifications
Engine ModelS6D102E
Displacement359 in³
Power Measured @2,200 rpm
Net Power132.8 hp

Dimensions

Dimensions specifications
Ground Clearance18 in
Height - Top of Cab115 in
Length of Track on Ground144 in
Tail Swing Radius113 in
Width to Outside of Tracks118 in
Removal Counterweight Clearance43 in

Undercarriage

Undercarriage specifications
Ground Pressure7 psi
Track Gauge95 in
Max Travel Speed3.5 mph
Shoe Size24 in

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth261 in
Max Reach Along Ground383 in
Max Loading Height256 in
Max Vertical Wall Digging Depth236 in
Max Cutting Height367 in
Shipping Length of Unit376 in
Shipping Height of Unit118 in

Bucket

Bucket specifications
Reference Bucket Capacity1.10 yd³

Swing Mechanism

Swing Mechanism specifications
Swing Speed12 rpm
