Komatsu

PC220-2

Excavator

Operating Weight
48,061 lb
Max Digging Depth
261 in
Max Digging Depth
277 in
Net Power
136.0 hp
All excavators
Komatsu PC220-2 Excavator
1 / 5
Image 1 of 5
Image: komatsu.com

Specifications

37 data points

Operating Specifications

Operating Specifications specifications
Operating Weight48,061 lb
Fuel Capacity68.7 gal
Hydraulic Pump Flow Capacity116.8 gal/min
Hydraulic System Fluid Capacity47.6 gal
Hydraulic System Relief Valve Pressure3,980 psi

Engine

Engine specifications
Engine ModelS6D105
Displacement396 in³
Net Power136.0 hp
Aspirationturbocharged

Dimensions

Dimensions specifications
Ground Clearance18 in
Height - Top of Cab117 in
Length of Track on Ground132 in
Tail Swing Radius115 in
Width to Outside of Tracks119 in
Removal Counterweight Clearance40 in

Undercarriage

Undercarriage specifications
Ground Pressure7 psi
Track Gauge95 in
Max Travel Speed1.4 mph
Shoe Size24 in

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth261 in
Max Reach Along Ground395 in
Max Loading Height253 in
Max Vertical Wall Digging Depth224 in
Max Cutting Height366 in
Shipping Length of Unit389 in
Shipping Height of Unit121 in

Swing Mechanism

Swing Mechanism specifications
Swing Speed12 rpm

Boom/Stick Excavator Option 2

Boom/Stick Excavator Option 2 specifications
Max Digging Depth277 in
Max Vertical Wall Digging Depth221 in
Max Cutting Height362 in
Max Loading Height254 in
Max Reach Along Ground407 in

Boom/Stick Excavator Option 3

Boom/Stick Excavator Option 3 specifications
Max Digging Depth294 in
Max Cutting Height367 in
Max Loading Height259 in
Max Vertical Wall Digging Depth238 in
Max Reach Along Ground420 in
