Komatsu
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Fuel Capacity | 84.5 gal |
|---|---|
| Hydraulic System Fluid Capacity | 43.6 gal |
| Engine Oil Capacity | 6.1 gal |
| Cooling System Fluid Capacity | 5.5 gal |
| Swing Drive Fluid Capacity | 1.9 gal |
Engine
| Engine Model | SAA6D107E-1 |
|---|---|
| Displacement | 408 in³ |
| Gross Power | 155.0 hp |
| Aspiration | Turbocharged and air-to-air aftercooled |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 120 in |
| Length of Track on Ground | 144 in |
| Tail Swing Radius | 66 in |
| Width to Outside of Tracks | 121 in |
| Removal Counterweight Clearance | 42 in |
| Digging Depth | 264 in |
| Digging Reach | 264 in |
Undercarriage
| Number of Track Rollers per Side | 9 |
|---|---|
| Max Travel Speed | 3.4 mph |
| Number of Shoes per Side | 49 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 4,631,064 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 261 in |
|---|---|
| Max Vertical Wall Digging Depth | 235 in |
Bucket
| Reference Bucket Capacity | 1.10 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.60 yd³ |
| Minimum Bucket Capacity | 0.71 yd³ |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 240 in |
|---|---|
| Max Vertical Wall Digging Depth | 210 in |
