Komatsu
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
44 data points
Operating Specifications
| Fuel Capacity | 105.7 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 118.9 gal/min |
| Engine Oil Capacity | 6.4 gal |
| Cooling System Fluid Capacity | 8.2 gal |
| Swing Drive Fluid Capacity | 1.8 gal |
Engine
| Engine Model | SAA6D102E-2 |
|---|---|
| Displacement | 21,908 in³ |
| Power Measured @ | 2,050 rpm |
| Gross Power | 189.1 hp |
| Aspiration | Turbocharged |
| Engine Make | Komatsu |
| Bore | 4 in |
| Stroke | 5 in |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 122 in |
| Length of Track on Ground | 159 in |
| Tail Swing Radius | 117 in |
| Width to Outside of Tracks | 130 in |
| Removal Counterweight Clearance | 47 in |
| Digging Depth | 288 in |
| Digging Reach | 288 in |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 102 in |
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 28 in |
| Number of Shoes per Side | 48 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 55,978 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 254 in |
|---|---|
| Max Reach Along Ground | 394 in |
| Max Loading Height | 277 in |
| Max Vertical Wall Digging Depth | 223 in |
| Max Cutting Height | 395 in |
| Shipping Length of Unit | 386 in |
| Shipping Height of Unit | 127 in |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 274 in |
|---|---|
| Max Vertical Wall Digging Depth | 234 in |
| Max Cutting Height | 400 in |
| Max Loading Height | 284 in |
| Max Reach Along Ground | 409 in |
| Shipping Length of Unit | 390 in |
| Shipping Height of Unit | 130 in |
