301.8C
Mini Excavator
95 specifications
1 / 5
Image 1 of 5
Specifications
47 data points
Operating Specifications
| Operating Weight | 6,548 lb |
|---|---|
| Fuel Capacity | 9.3 gal |
| Hydraulic Pump Flow Capacity | 20.2 gal/min |
| Hydraulic System Fluid Capacity | 7.7 gal |
| Hydraulic System Relief Valve Pressure | 3,046 psi |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 A |
| Engine Oil Capacity | 1.4 gal |
| Cooling System Fluid Capacity | 1.1 gal |
Engine
| Engine Model | 3D82AE-3FA |
|---|---|
| Displacement | 81 in³ |
| Power Measured @ | 2,600 rpm |
| Gross Power | 29.4 hp |
| Net Power | 26.0 hp |
| Number of Cylinders | 3 |
| Aspiration | Natural |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 60 lb-ft |
Dimensions
| Height - Top of Cab | 98 in |
|---|---|
| Length of Track on Ground | 59 in |
| Tail Swing Radius | 49 in |
| Width to Outside of Tracks | 60 in |
| Removal Counterweight Clearance | 24 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Track Gauge | 48 in |
| Number of Track Rollers per Side | 4 |
| Max Travel Speed | 2.8 mph |
| Shoe Size | 12 in |
| Number of Shoes per Side | 40 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 104 in |
|---|---|
| Max Reach Along Ground | 186 in |
| Max Vertical Wall Digging Depth | 86 in |
| Max Loading Height | 124 in |
| Shipping Length of Unit | 179 in |
| Max Cutting Height | 174 in |
| Shipping Height of Unit | 98 in |
Bucket
| Reference Bucket Capacity | 0.20 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.20 yd³ |
| Minimum Bucket Capacity | 0.10 yd³ |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 115 in |
|---|---|
| Max Cutting Height | 183 in |
| Max Loading Height | 133 in |
| Max Vertical Wall Digging Depth | 102 in |
| Max Reach Along Ground | 200 in |
| Shipping Height of Unit | 98 in |
| Shipping Length of Unit | 183 in |
