Komatsu
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Fuel Capacity | 160.0 gal |
|---|---|
| Hydraulic System Fluid Capacity | 49.7 gal |
| Engine Oil Capacity | 9.2 gal |
| Cooling System Fluid Capacity | 8.5 gal |
| Swing Drive Fluid Capacity | 3.5 gal |
Engine
| Engine Model | SAA6D114E |
|---|---|
| Power Measured @ | 1,900 rpm |
| Net Power | 242.0 hp |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 124 in |
| Length of Track on Ground | 196 in |
| Tail Swing Radius | 137 in |
| Digging Depth | 312 in |
| Digging Reach | 312 in |
Undercarriage
| Number of Track Rollers per Side | 8 |
|---|---|
| Max Travel Speed | 3.4 mph |
| Number of Shoes per Side | 48 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 59,300 lb |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
