Komatsu
PC308USLC-3
- Operating Weight
- 71,938 lb
- Max Digging Depth
- 254 in
- Max Digging Depth
- 274 in
- Net Power
- 187.0 hp
1 / 5
Image 1 of 5
Specifications
44 data points
Operating Specifications
| Operating Weight | 71,938 lb |
|---|---|
| Fuel Capacity | 103.0 gal |
| Hydraulic System Fluid Capacity | 55.5 gal |
| Engine Oil Capacity | 6.1 gal |
| Cooling System Fluid Capacity | 5.5 gal |
| Swing Drive Fluid Capacity | 2.2 gal |
Engine
| Engine Model | SAA6D107E-1 |
|---|---|
| Displacement | 408 in³ |
| Gross Power | 200.0 hp |
| Net Power | 187.0 hp |
| Aspiration | Turbocharged and air to air aftercooled |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 124 in |
| Length of Track on Ground | 159 in |
| Tail Swing Radius | 137 in |
| Width to Outside of Tracks | 137 in |
| Removal Counterweight Clearance | 48 in |
Undercarriage
| Number of Track Rollers per Side | 8 |
|---|---|
| Max Travel Speed | 2.9 mph |
| Number of Shoes per Side | 48 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 59,180 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 254 in |
|---|---|
| Max Reach Along Ground | 411 in |
| Max Loading Height | 283 in |
| Max Vertical Wall Digging Depth | 234 in |
| Max Cutting Height | 400 in |
| Shipping Length of Unit | 377 in |
Bucket
| Reference Bucket Capacity | 1.60 yd³ |
|---|---|
| Maximum Bucket Capacity | 2.50 yd³ |
| Minimum Bucket Capacity | 0.90 yd³ |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 274 in |
|---|---|
| Max Vertical Wall Digging Depth | 234 in |
| Max Cutting Height | 400 in |
| Max Loading Height | 283 in |
| Max Reach Along Ground | 411 in |
| Shipping Length of Unit | 377 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 299 in |
|---|---|
| Max Cutting Height | 422 in |
| Max Loading Height | 315 in |
| Max Vertical Wall Digging Depth | 272 in |
| Max Reach Along Ground | 441 in |
| Shipping Length of Unit | 374 in |
