Liebherr
JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
47 data points
Operating Specifications
| Operating Weight | 43,200 lb |
|---|---|
| Fuel Capacity | 66.0 gal |
| Hydraulic Pump Flow Capacity | 79.0 gal/min |
| Hydraulic System Fluid Capacity | 79.3 gal |
| Hydraulic System Relief Valve Pressure | 5,076 psi |
| Hydraulic Pump Type | Liebherr axial piston variable displacement pump |
Engine
| Engine Model | Liebherr D924 |
|---|---|
| Displacement | 275 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 154.0 hp |
| Number of Cylinders | 4 |
| Bore | 4 in |
| Stroke | 5 in |
| Engine Type | 4 cylinder in-line |
| Cooling system | Water-cooled |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 126 in |
| Wheelbase | 101 in |
| Overall Width | 99 in |
| Tail Swing Radius | 73 in |
Transmission
| Max Travel Speed | 18.6 mph |
|---|
Bucket
| Maximum Bucket Capacity | 1.40 yd³ |
|---|---|
| Minimum Bucket Capacity | 0.30 yd³ |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|---|
| Swing Torque | 36,878 lb-ft |
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 215 in |
|---|---|
| Max Reach Along Ground | 344 in |
| Shipping Length of Unit | 330 in |
| Shipping Height of Unit | 118 in |
| Max Dumping Height | 278 in |
| Max breakout force | 22,000 lb |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 207 in |
|---|---|
| Max Reach Along Ground | 337 in |
| Shipping Height of Unit | 125 in |
| Shipping Length of Unit | 328 in |
| Max Dumping Height | 253 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 221 in |
|---|---|
| Max Reach Along Ground | 348 in |
| Shipping Height of Unit | 127 in |
| Shipping Length of Unit | 328 in |
Electrical System
| Batteries | 2 x 135 Ah/12 volts |
|---|---|
| Alternator | — |
| Voltage | 24 V |
Boom/Stick Mobile Excavator Option 4
| Max Digging Depth | 196 in |
|---|---|
| Max Reach Along Ground | 332 in |
| Shipping Height of Unit | 125 in |
| Shipping Length of Unit | 325 in |
