Komatsu
Hitachi
EX220LC-3
Excavator
51 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Operating Weight | 71,209 lb |
|---|---|
| Fuel Capacity | 159.9 gal |
| Hydraulic Pump Flow Capacity | 141.4 gal/min |
| Engine Oil Capacity | 9.3 gal |
| Cooling System Fluid Capacity | 8.5 gal |
| Swing Drive Fluid Capacity | 3.6 gal |
Engine
| Engine Model | SAA6D114E |
|---|---|
| Displacement | 505 in³ |
| Power Measured @ | 1,900 rpm |
| Net Power | 241.4 hp |
| Aspiration | Turbocharged |
| Engine Make | Komatsu |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 124 in |
| Length of Track on Ground | 146 in |
| Tail Swing Radius | 137 in |
| Width to Outside of Tracks | 126 in |
| Removal Counterweight Clearance | 47 in |
Undercarriage
| Ground Pressure | 10 psi |
|---|---|
| Number of Track Rollers per Side | 7 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 45 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 59,350 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 292 in |
|---|---|
| Max Reach Along Ground | 431 in |
| Max Loading Height | 281 in |
| Max Vertical Wall Digging Depth | 256 in |
| Max Cutting Height | 402 in |
Bucket
| Maximum Bucket Capacity | 1.90 yd³ |
|---|
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
