Komatsu
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
61 data points
Operating Specifications
| Fuel Capacity | 171.8 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 182.3 gal/min |
| Hydraulic System Fluid Capacity | 65.6 gal |
| Engine Oil Capacity | 9.8 gal |
| Swing Drive Fluid Capacity | 5.3 gal |
Engine
| Engine Model | SAA6D125E-7 |
|---|---|
| Displacement | 674 in³ |
| Power Measured @ | 1,900 rpm |
| Gross Power | 362.1 hp |
| Engine Make | Komatsu |
| Bore | 5 in |
| Stroke | 6 in |
Dimensions
| Ground Clearance | 28 in |
|---|---|
| Height - Top of Cab | 133 in |
| Length of Track on Ground | 212 in |
| Tail Swing Radius | 144 in |
| Width to Outside of Tracks | 119 in |
| Removal Counterweight Clearance | 55 in |
Undercarriage
| Track Gauge | 114 in |
|---|---|
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 49 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 75 lb |
Boom/Stick Excavator Option 1
| Max Loading Height | 282 in |
|---|---|
| Max Vertical Wall Digging Depth | 206 in |
| Max Cutting Height | 409 in |
| Shipping Length of Unit | 469 in |
| Shipping Height of Unit | 154 in |
General Specifications
| Operating Weight lbs (kg) | 107,850 (48,920) Starting 2025 Model Year |
|---|---|
| Digging Depth ft (m) | 30.2 (9.19) Starting 2025 Model Year |
| Digging Reach ft. (m) | 43.8 (13.37) Starting 2025 Model Year |
| Engine hp (kW) | 359 (268) Starting 2025 Model Year |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 287 in |
|---|---|
| Max Vertical Wall Digging Depth | 222 in |
| Max Cutting Height | 408 in |
| Max Loading Height | 282 in |
| Max Reach Along Ground | 442 in |
| Shipping Length of Unit | 473 in |
| Shipping Height of Unit | 149 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 306 in |
|---|---|
| Max Cutting Height | 433 in |
| Max Loading Height | 301 in |
| Max Vertical Wall Digging Depth | 269 in |
| Max Reach Along Ground | 466 in |
| Shipping Length of Unit | 470 in |
Boom/Stick Excavator Option 4
| Max Digging Depth | 330 in |
|---|---|
| Max Cutting Height | 437 in |
| Max Reach Along Ground | 487 in |
| Max Loading Height | 307 in |
| Max Vertical Wall Dig Depth | 284 in |
| Shipping Length of Unit | 472 in |
Boom/Stick Excavator Option 5
| Max Digging Depth | 362 in |
|---|---|
| Max Reach Along Ground | 520 in |
| Max Cutting Height | 455 in |
| Max Loading Height | 324 in |
| Max Vertical Wall Dig Depth | 319 in |
| Shipping Height of Unit | 175 in |
| Shipping Length of Unit | 466 in |
