Komatsu
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
60 data points
Operating Specifications
| Fuel Capacity | 66.1 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 79.0 gal/min |
| Hydraulic System Fluid Capacity | 35.7 gal |
| Hydraulic System Relief Valve Pressure | 4,623 psi |
| Engine Oil Capacity | 4.3 gal |
| Cooling System Fluid Capacity | 5.3 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 45 A |
| Hydraulic Pump Type | variable displacement piston pump |
| Oscillating Axle Angle | 14 ° |
| Front Diff Fluid Capacity | 4.0 gal |
| Rear Diff Fluid Capacity | 5.3 gal |
Engine
| Engine Model | SA4D102E-1 |
|---|---|
| Displacement | 239 in³ |
| Power Measured @ | 2,300 rpm |
| Gross Power | 124.8 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 124 in |
| Wheelbase | 103 in |
| Overall Width | 8 in |
| Tail Swing Radius | 102 in |
| Digging Depth | 216 in |
| Digging Reach | 216 in |
| Upper Structure Clearance | 50 in |
Transmission
| Max Travel Speed | 18.7 mph |
|---|---|
| Transmission Type | Full Automatic |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Bucket
| Reference Bucket Capacity | 0.99 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.50 yd³ |
| Minimum Bucket Capacity | 0.41 yd³ |
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 196 in |
|---|---|
| Max Cutting Height | 356 in |
| Max Reach Along Ground | 320 in |
| Max Loading Height | 251 in |
| Shipping Length of Unit | 340 in |
| Shipping Height of Unit | 133 in |
| Max Vertical Wall Dig Depth | 163 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 211 in |
|---|---|
| Max Cutting Height | 360 in |
| Max Reach Along Ground | 333 in |
| Max Loading Height | 256 in |
| Shipping Height of Unit | 131 in |
| Shipping Length of Unit | 339 in |
| Max Vertical Wall Dig Depth | 185 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 226 in |
|---|---|
| Max Cutting Height | 362 in |
| Max Reach Along Ground | 346 in |
| Max Loading Height | 259 in |
| Shipping Height of Unit | 125 in |
| Shipping Length of Unit | 337 in |
| Max Vertical Wall Dig Depth | 216 in |
Boom/Stick Mobile Excavator Option 4
| Max Digging Depth | 190 in |
|---|---|
| Max Cutting Height | 352 in |
| Max Reach Along Ground | 318 in |
| Max Loading Height | 246 in |
| Max Vertical Wall Dig Depth | 163 in |
