Komatsu
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Operating Weight | 6,482 lb |
|---|---|
| Max Speed | 10.0 mph |
| Fuel Capacity | 14.1 gal |
| Hydraulic System Fluid Capacity | 10.1 gal |
| Tire Size | 10-16.5 8PR |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 A |
| Engine Oil Fluid Capacity | 2.2 gal |
| Cooling System Fluid Capacity | 2.2 gal |
| Chain Box Fluid Capacity - each side | 8.2 gal |
| Operating Speed | 6.6 mph |
Engine
| Engine Model | S4D84E-1FD |
|---|---|
| Displacement | 122 in³ |
| Power Measured @ | 2,800 rpm |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
Hydraulic System
| Pump Flow Capacity | 15.9 gal/min |
|---|---|
| Relief Valve Pressure | 3,046 psi |
| Pump Type | Komatsu Gear |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 79 in |
| Wheelbase | 42 in |
| Width Over Tires | 66 in |
| Reach at Max Lift and Dump | 26 in |
| Length with Bucket | 138 in |
| Clearance at Max Lift and Dump | 86 in |
| Turning Radius from Center - inc bucket | 79 in |
| Turning Radius from Center - machine rear | 66 in |
Loader
| Bucket Capacity | 0.80 yd³ |
|---|---|
| Operating Load Rating | 1,905 lb |
| Tipping Angle | 3,807 ° |
| Breakout Force | 3,530 psi |
