Komatsu
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 52,646 lb |
|---|---|
| Fuel Capacity | 113.6 gal |
| Tire Size | 29.5-25-22PR (L-3) |
| Static Tipping Weight | 42,549 lb |
| Turning Radius | 311 in |
| Rear Axle Oscillation | 30 ° |
| Cooling System Fluid Capacity | 22.8 gal |
Engine
| Engine Model | Cummins NT855 |
|---|---|
| Displacement | 854 in³ |
| Gross Power | 280.0 hp |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 144 in |
| Wheelbase | 141 in |
| Width Over Tires | 121 in |
| Reach at Max Lift and Dump | 52 in |
| Length with Bucket on Ground | 333 in |
| Hinge Pin - Max Height | 168 in |
Transmission
| Max Speed - Forward | 20.2 mph |
|---|---|
| Max Speed - Reverse | 20.2 mph |
| Transmission Type | TORQFLOW countershaft full soft-shift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 5.30 yd³ |
|---|---|
| Dump Clearance at Max Raise | 122 in |
| Breakout Force | 26,060 lb |
| Bucket Width | 131 in |
