Komatsu
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
42 data points
Operating Specifications
| Operating Weight | 42,031 lb |
|---|---|
| Fuel Capacity | 79.3 gal |
| Tire Size | 23.5 R25 - 750/65 R25 |
| Hydraulic System Fluid Capacity | 34.1 gal |
| Static Tipping Weight | 34,227 lb |
| Operating Voltage | 24 V |
| Turning Radius | 238 in |
| Engine Oil Fluid Capacity | 8.5 gal |
| Alternator Supplied Amperage | 60 A |
| Front Axle/Diff Fluid Capacity | 10.1 gal |
| Rear Axle/Diff Fluid Capacity | 10.1 gal |
| Cooling System Fluid Capacity | 9.6 gal |
| Transmission Fluid Capacity | 10.1 gal |
Engine
| Engine Model | SAA6D114 E-2 |
|---|---|
| Displacement | 505 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 208.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharger |
| Torque Measured @ | 1,400 rpm |
Hydraulic System
| Pump Flow Capacity | 79.8 gal/min |
|---|---|
| Raise Time | 5.3 s |
| Lower Time | 2.7 s |
| Dump Time | 1.2 s |
| Relief Valve Setting | 3,046 psi |
| Pump Type | gear pump |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 134 in |
| Wheelbase | 131 in |
| Width Over Tires | 117 in |
| Reach at Max Lift and Dump | 44 in |
| Length with Bucket on Ground | 325 in |
| Hinge Pin - Max Height | 165 in |
Transmission
| Max Speed - Forward | 24.0 mph |
|---|---|
| Max Speed - Reverse | 24.7 mph |
| Transmission Type | Automatic powershift transmission |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 4.39 yd³ |
|---|---|
| Dump Clearance at Max Raise | 118 in |
| Breakout Force | 36,509 lb |
| Bucket Width | 119 in |
