Komatsu
TCM
L3-2
Wheel Loader
16 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight 2wd | 6,812 lb |
|---|---|
| Fuel Capacity | 8.0 gal |
| Turning Radius | 144 in |
| Cooling System Fluid Capacity | 2.5 gal |
| Tire Size Front - 2wd / 4wd | 33x12.5-15-6PR (L-2) |
Engine
| Engine Model | 2D94-2 |
|---|---|
| Displacement | 90 in³ |
| Gross Power | 26.2 hp |
Dimensions
| Ground Clearance | 9 in |
|---|---|
| Wheelbase | 66 in |
| Transport Width | 60 in |
| Transport Length | 165 in |
Transmission
| Max Speed - Reverse | 9.4 mph |
|---|---|
| Max Speed | 9.4 mph |
| Transmission Type | planetary gear |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Tires & Wheels
| Rear Tires Size | 33x12.5-15-6PR (L-2) |
|---|
Backhoe
| Dig Depth | 101 in |
|---|---|
| Load Height | 78 in |
| Reach From Swivel | 134 in |
| Bucket Dig Force | 4,145 lb |
Loader
| Bucket Capacity | 0.50 yd³ |
|---|---|
| Bucket Width | 62 in |
| Clearance at Max Dump Height | 79 in |
| Bucket Breakout Force | 5,140 lb |
| Reach at Max Dump Height | 28 in |
