Komatsu
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Fuel Capacity | 79.3 gal |
|---|---|
| Tire Size | 23.5-25 |
| Hydraulic System Fluid Capacity | 37.5 gal |
| Turning Radius | 251 in |
| Engine Oil Fluid Capacity | 6.1 gal |
| Front Axle/Diff Fluid Capacity | 10.6 gal |
| Rear Axle/Diff Fluid Capacity | 10.6 gal |
| Cooling System Fluid Capacity | 14.4 gal |
| Transmission Fluid Capacity | 14.3 gal |
| Rated Bucket Capacity | 3.81 – 5.21 yd³ |
Engine
| Engine Model | SAA6D107E-2 |
|---|---|
| Displacement | 408 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 143.0 hp |
| Net Power | 142.0 hp |
| Number of Cylinders | 6 |
| Aspiration | TURBOCHARGED |
Weights
| Operating Weight | 39,840 – 41,115 lb |
|---|
Hydraulic System
| Pump Flow Capacity | 36.2 gal/min |
|---|---|
| Raise Time | 5.9 s |
| Lower Time | 3.3 s |
| Dump Time | 1.8 s |
| Relief Valve Setting | 3,555 psi |
| Pump Type | PISTON PUMP |
Transmission
| Max Speed - Forward | 40.0 mph |
|---|---|
| Max Speed - Reverse | 40.0 mph |
| Transmission Type | FULL POWERSHIFT |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Dump Clearance at Max Raise | 117 in |
|---|
