Komatsu
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 40,168 lb |
|---|---|
| Fuel Capacity | 84.6 gal |
| Tire Size | 23.5-25-16PR |
| Static Tipping Weight | 29,575 lb |
| Turning Radius | 261 in |
Engine
| Engine Model | S6D108 |
|---|---|
| Displacement | 436 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 217.3 hp |
| Number of Cylinders | 6 |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 133 in |
| Wheelbase | 131 in |
| Width Over Tires | 111 in |
| Reach at Max Lift and Dump | 44 in |
| Length with Bucket on Ground | 322 in |
| Hinge Pin - Max Height | 168 in |
Transmission
| Max Speed - Forward | 20.4 mph |
|---|---|
| Max Speed - Reverse | 21.1 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 4.90 yd³ |
|---|---|
| Bucket Capacity - struck | 4.20 yd³ |
| Dump Clearance at Max Raise | 124 in |
| Breakout Force | 40,800 lb |
| Bucket Width | 121 in |
