Komatsu
WA450-6
- Operating Weight
- 49,780 lb
- Bucket Capacity - heaped
- 5.49 yd³
- Gross Power
- 273.0 hp
- Net Power
- 272.0 hp
1 / 5
Image 1 of 5
Specifications
39 data points
Operating Specifications
| Operating Weight | 49,780 lb |
|---|---|
| Fuel Capacity | 109.1 gal |
| Hydraulic System Fluid Capacity | 45.7 gal |
| Static Tipping Weight | 39,860 lb |
| Turning Radius | 602 in |
| Engine Oil Fluid Capacity | 10.0 gal |
| Front Axle/Diff Fluid Capacity | 15.9 gal |
| Rear Axle/Diff Fluid Capacity | 14.8 gal |
| Cooling System Fluid Capacity | 16.1 gal |
| Transmission Fluid Capacity | 14.3 gal |
| Rated Bucket Capacity | 5.00 – 6.80 yd³ |
Engine
| Engine Model | SAA6D123E-5 |
|---|---|
| Displacement | 674 in³ |
| Gross Power | 273.0 hp |
| Net Power | 272.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbo-charged |
Weights
| Operating Weight | 49,780 – 50,080 lb |
|---|
Hydraulic System
| Pump Flow Capacity | 63.9 gal/min |
|---|---|
| Raise Time | 6.0 s |
| Lower Time | 3.7 s |
| Dump Time | 1.6 s |
| Relief Valve Setting | 3,555 psi |
| Pump Type | Double-acting piston type |
Dimensions
| Ground Clearance | 22 in |
|---|---|
| Height - Top of Cab | 138 in |
| Wheelbase | 137 in |
| Width Over Tires | 120 in |
| Length with Bucket on Ground | 354 in |
| Hinge Pin - Max Height | 173 in |
Transmission
| Max Speed - Forward | 21.7 mph |
|---|---|
| Max Speed - Reverse | 22.4 mph |
| Transmission Type | Full-powershift countershaft type. |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 5.49 yd³ |
|---|---|
| Dump Clearance at Max Raise | 126 in |
| Breakout Force | 43,160 lb |
| Bucket Width | 126 in |
