Komatsu
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 47,642 lb |
|---|---|
| Fuel Capacity | 105.7 gal |
| Tire Size | 23.5-25-20PR |
| Static Tipping Weight | 36,079 lb |
| Turning Radius | 272 in |
Engine
| Engine Model | S6D125 |
|---|---|
| Displacement | 671 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 260.2 hp |
| Number of Cylinders | 6 |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 134 in |
| Wheelbase | 134 in |
| Width Over Tires | 115 in |
| Reach at Max Lift and Dump | 50 in |
| Length with Bucket on Ground | 343 in |
| Hinge Pin - Max Height | 169 in |
Transmission
| Max Speed - Forward | 19.6 mph |
|---|---|
| Max Speed - Reverse | 20.4 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 5.49 yd³ |
|---|---|
| Bucket Capacity - struck | 4.80 yd³ |
| Dump Clearance at Max Raise | 124 in |
| Breakout Force | 43,200 lb |
| Bucket Width | 126 in |
