Komatsu
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 52,514 lb |
|---|---|
| Fuel Capacity | 103.1 gal |
| Tire Size | 265 R25 |
| Hydraulic System Fluid Capacity | 49.2 gal |
| Static Tipping Weight | 45,515 lb |
Engine
| Engine Model | SAA6 D125E-3 |
|---|---|
| Displacement | 674 in³ |
| Power Measured @ | 1,700 rpm |
| Gross Power | 270.9 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharger |
| Torque Measured @ | 1,400 rpm |
| Max torque ISO TR14396 | 1,245 lb-ft |
Hydraulic System
| Pump Flow Capacity | 108.4 gal/min |
|---|---|
| Relief Valve Setting | 3,046 psi |
| Pump Type | gear pump |
Dimensions
| Height - Top of Cab | 137 in |
|---|---|
| Wheelbase | 137 in |
| Width Over Tires | 115 in |
| Length with Bucket on Ground | 939 in |
Transmission
| Transmission Type | speed powershift |
|---|---|
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 5.40 yd³ |
|---|
