Komatsu

WA80-3

Wheel Loader

Bucket Capacity - heaped
1.20 yd³
Gross Power
59.1 hp
All wheel loaders
Komatsu WA80-3 Wheel Loader
1 / 5
Image 1 of 5
Image: gsat.jp

Specifications

21 data points

Operating Specifications

Operating Specifications specifications
Fuel Capacity19.9 gal
Tire Size17.5/65-20

Engine

Engine specifications
Engine Model4D102E
Displacement239 in³
Power Measured @1,850 rpm
Gross Power59.1 hp
Number of Cylinders4

Dimensions

Dimensions specifications
Ground Clearance13 in
Height - Top of Cab113 in
Wheelbase89 in
Width Over Tires76 in
Reach at Max Lift and Dump36 in
Length with Bucket on Ground209 in
Hinge Pin - Max Height122 in

Transmission

Transmission specifications
Max Speed - Forward19.9 mph
Max Speed - Reverse19.9 mph
Number of Forward Gears2
Number of Reverse Gears2

Bucket

Bucket specifications
Bucket Capacity - heaped1.20 yd³
Bucket Capacity - struck0.99 yd³
Dump Clearance at Max Raise97 in
