Kubota

BX23

Tractor

Operating Weight
1,521 lb
Displacement
55 in³
Power Measured @
3,200 rpm
Gross Power
22.0 hp
All tractors
Kubota BX23 Tractor
1 / 5
Image 1 of 5
Image: coastlinemowers.com.au

Specifications

21 data points

Operating Specifications

Operating Specifications specifications
Operating Weight1,521 lb
Fuel Capacity5.6 gal
3 Point Hitch Lift Capacity @ 24 inches683 lb
3 Point Hitch Typecat. I
Turning Radius91 in

Engine

Engine specifications
Engine ModelD905-E-BX
Displacement55 in³
Power Measured @3,200 rpm
Gross Power22.0 hp
Number of Cylinders3
AspirationE-TVCS liquid cooled
PTO Power16.7 hp

Hydraulic System

Hydraulic System specifications
Pump Flow Capacity5.6 gal/min

Dimensions

Dimensions specifications
Ground Clearance7 in
Height - Top of Cab86 in
Wheelbase55 in
Overall Length7 in
Tire Sizefront 18x8.50-8turf rear 26x12.00-12 turf
Width Outside Frame46 in

Transmission

Transmission specifications
Max Speed8.1 mph
Transmission TypeHST 2 range
