KubotaKubota
B2920
Tractor
23 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 1,543 lb |
|---|---|
| Fuel Capacity | 6.7 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 661 lb |
| 3 Point Hitch Type | cat. I |
| Turning Radius | 91 in |
| Cooling System Fluid Capacity | 0.8 gal |
| Engine Oil Capacity | 0.9 gal |
Engine
| Engine Model | D902 |
|---|---|
| Displacement | 55 in³ |
| Power Measured @ | 3,200 rpm |
| Gross Power | 23.0 hp |
| Number of Cylinders | 3 |
| Aspiration | E-TVCS liquid cooled |
| PTO Power | 17.7 hp |
Hydraulic System
| Pump Flow Capacity | 6.4 gal/min |
|---|
Dimensions
| Ground Clearance | 9 in |
|---|---|
| Wheelbase | 55 in |
| Overall Length | 8 in |
| Tire Size | front 18x8.50-10 turf rear 26x12.00-12 turf |
| Width Outside Frame | 32 in |
Transmission
| Max Speed | 8.1 mph |
|---|---|
| Transmission Type | HST 2 range |
Axles
| Final Drive | Spur gear |
|---|
