Kubota
YTO
DFH-1004
Tractor
11 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 9,006 lb |
|---|---|
| Fuel Capacity | 50.2 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 5,203 lb |
| 3 Point Hitch Type | Cat II |
| Turning Radius | 158 in |
| Alternator Supplied Amperage | 80 A |
| Operating Voltage | 12 V |
Engine
| Engine Model | V3800TIE2 |
|---|---|
| Displacement | 230 in³ |
| Power Measured @ | 2,600 rpm |
| Net Power | 105.0 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
| PTO Power | 90.0 hp |
Hydraulic System
| Pump Flow Capacity | 18.1 gal/min |
|---|---|
| Number of Remote Control Valves | 2 |
Dimensions
| Ground Clearance | 23 in |
|---|---|
| Wheelbase | 96 in |
| Overall Length | 14 in |
| Tire Size | front 13.6R24 rear 18.4R34 |
| Width Outside Frame | 84 in |
Transmission
| Max Speed | 21.5 mph |
|---|---|
| Number of Forward Gears | 16 |
| Transmission Type | Intelli-Shift dual-range power shift |
| Number of Reverse Gears | 16 |
