Kubota
Landini
Rex 85 S
Tractor
22 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 9,700 lb |
|---|---|
| Fuel Capacity | 50.2 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 5,203 lb |
| 3 Point Hitch Type | Cat II |
| Turning Radius | 162 in |
| Alternator Supplied Amperage | 80 A |
| Operating Voltage | 12 V |
Engine
| Engine Model | F5802TE2 |
|---|---|
| Displacement | 356 in³ |
| Power Measured @ | 2,400 rpm |
| Net Power | 125.0 hp |
| Number of Cylinders | 5 |
| Aspiration | turbocharged |
| PTO Power | 103.0 hp |
Hydraulic System
| Pump Flow Capacity | 20.1 gal/min |
|---|---|
| Number of Remote Control Valves | 2 |
Dimensions
| Ground Clearance | 24 in |
|---|---|
| Wheelbase | 107 in |
| Overall Length | 14 in |
| Tire Size | front 14.9R24 rear 18.4R38 |
| Width Outside Frame | 84 in |
Transmission
| Max Speed | 22.4 mph |
|---|---|
| Number of Forward Gears | 16 |
| Transmission Type | Intelli-Shift dual-range power shift |
| Number of Reverse Gears | 16 |
