Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Fuel Capacity | 1,050.0 gal |
|---|---|
| Tire Size | 58/85-57 84 PR (L-4) |
| Hydraulic System Fluid Capacity | 374.9 gal |
| Engine Oil Fluid Capacity | 53.9 gal |
| Rear Axle Oscillation | 22 ° |
| Front Axle/Diff Fluid Capacity | 25.1 gal |
| Rear Axle/Diff Fluid Capacity | 25.1 gal |
| Cooling System Fluid Capacity | 109.9 gal |
| Transmission Fluid Capacity | 7.2 gal |
Engine
| Engine Model | QSK 60 |
|---|---|
| Displacement | 2,746 in³ |
| Power Measured @ | 1,900 rpm |
| Gross Power | 2,000.0 hp |
| Number of Cylinders | 16 |
| Aspiration | turbocharged |
Hydraulic System
| Pump Flow Capacity | 499.9 gal/min |
|---|---|
| Raise Time | 14.0 s |
| Lower Time | 6.0 s |
| Dump Time | 4.0 s |
| Relief Valve Setting | 3,300 psi |
| Pump Type | piston |
Dimensions
| Ground Clearance | 30 in |
|---|---|
| Height - Top of Cab | 264 in |
| Wheelbase | 276 in |
| Width Over Tires | 239 in |
Transmission
| Max Speed - Forward | 10.6 mph |
|---|---|
| Max Speed - Reverse | 10.6 mph |
| Transmission Type | infinitely variable |
Bucket
| Bucket Width | 252 in |
|---|
