Liebherr
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Operating Weight | 55,510 lb |
|---|---|
| Fuel Capacity | 106.0 gal |
| Tire Size | 26.5 R 25 |
| Hydraulic System Fluid Capacity | 70.0 gal |
| Static Tipping Weight | 40,785 lb |
| Engine Oil Fluid Capacity | 11.6 gal |
| Front Axle/Diff Fluid Capacity | 11.1 gal |
| Rear Axle/Diff Fluid Capacity | 11.1 gal |
| Cooling System Fluid Capacity | 13.7 gal |
| Transmission Fluid Capacity | 3.0 gal |
Engine
| Engine Model | D936 A7 |
|---|---|
| Displacement | 642 in³ |
| Gross Power | 288.0 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,100 rpm |
| Max Torque | 1,033 lb-ft |
Hydraulic System
| Pump Flow Capacity | 77.0 gal/min |
|---|---|
| Raise Time | 5.5 s |
| Lower Time | 3.5 s |
| Dump Time | 2.0 s |
Dimensions
| Ground Clearance | 23 in |
|---|---|
| Height - Top of Cab | 143 in |
| Wheelbase | 145 in |
| Reach at Max Lift and Dump | 47 in |
| Length with Bucket on Ground | 381 in |
| Hinge Pin - Max Height | 180 in |
Transmission
| Max Speed - Forward | 24.9 mph |
|---|---|
| Max Speed - Reverse | 24.9 mph |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 6.50 yd³ |
|---|---|
| Dump Clearance at Max Raise | 122 in |
| Breakout Force | 42,715 lb |
| Bucket Width | 121 in |
