Liebherr
L586 XPOWER
- Operating Weight
- 71,870 lb
- Bucket Capacity - heaped
- 7.80 yd³
- Gross Power
- 353.0 hp
- Net Power
- 349.0 hp
1 / 5
Image 1 of 5
Specifications
48 data points
Operating Specifications
| Operating Weight | 71,870 lb |
|---|---|
| Fuel Capacity | 132.0 gal |
| Tire Size | 29.5R25 L3 |
| Hydraulic System Fluid Capacity | 55.5 gal |
| Static Tipping Weight | 47,620 lb |
| Turning Radius | 330 in |
| Engine Oil Fluid Capacity | 10.6 gal |
| Front Axle/Diff Fluid Capacity | 15.9 gal |
| Rear Axle/Diff Fluid Capacity | 15.9 gal |
| Cooling System Fluid Capacity | 19.3 gal |
| Hydraulic Fluid Capacity | 25.1 gal |
Engine
| Engine Model | D936 A7 |
|---|---|
| Displacement | 642 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 353.0 hp |
| Net Power | 349.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Water-cooled in-line engine with charge-air cooling exhaust after-treatment through Liebherr-SCR technology |
| Torque Measured @ | 1,100 rpm |
| Max Torque | 1,450 lb-ft |
| Stroke | 6 in |
| Bore | 5 in |
| Air cleaner | Dry type filter with main and safety element pre-cleaner service indicator on the Liebherr display |
| Fuel injection | Electronic Common Rail high-pressure injection |
Hydraulic System
| Pump Flow Capacity | 108.0 gal/min |
|---|---|
| Raise Time | 6.5 s |
| Lower Time | 4.0 s |
| Dump Time | 3.0 s |
| Relief Valve Setting | 4,351 psi |
| Pump Type | Load-sensing variable axial piston pump with output and flow control and pressure cut-off in the control block |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 148 in |
| Wheelbase | 145 in |
| Reach at Max Lift and Dump | 57 in |
| Length with Bucket on Ground | 395 in |
| Hinge Pin - Max Height | 183 in |
Transmission
| Max Speed - Forward | 20.5 mph |
|---|---|
| Max Speed - Reverse | 20.5 mph |
Bucket
| Bucket Capacity - heaped | 7.80 yd³ |
|---|---|
| Dump Clearance at Max Raise | 130 in |
| Breakout Force | 53,954 lb |
| Bucket Width | 135 in |
| Digging depth | 48 in |
| Arm length | 125 in |
Electrical System
| Voltage | 24 V |
|---|---|
| Alternator | — |
| Battery | 2 x 180 Ah |
| Starter | 24/10.5 (V/HP) |
