933C LGP
Crawler Loader
38 specifications
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 24,648 lb |
|---|---|
| Bucket Capacity - struck | 1.80 yd³ |
| Max Speed | 5.9 mph |
| Fuel Capacity | 55.5 gal |
| Static Tipping Load | 16,175 lb |
| Cooling System Fluid Capacity | 6.4 gal |
| Hydraulic System Fluid Capacity | 43.1 gal |
| Final Drive Fluid Capacity - each | 2.4 gal |
| Engine Oil Capacity | 3.2 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 55 A |
Engine
| Engine Model | 4045HF289 |
|---|---|
| Displacement | 275 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 97.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
Hydraulic System
| Pump Flow Capacity | 30.4 gal/min |
|---|---|
| Lower Time | 3.1 s |
| Raise Time | 6.4 s |
| Relief Valve Pressure | 3,335 psi |
| Dump Time | 1.9 s |
| Pump Type | gear |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 119 in |
| Width to Outside of Tracks | 81 in |
| Length with Bucket on Ground | 226 in |
| Reach at Dump Height | 37 in |
| Clearance at Full Height and Dump | 103 in |
| Length to Front of Track | 152 in |
Undercarriage
| Length of Track on Ground | 86 in |
|---|---|
| Track Gauge | 63 in |
| Track Shoe Width | 18 in |
| Ground Pressure | 8 psi |
| Number of Track Rollers per Side | 6 |
| Number of Shoes per Side | 38 |
