Liebherr
Caterpillar
973C WH
Crawler Loader
14 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 46,617 lb |
|---|---|
| Bucket Capacity - struck | 3.10 yd³ |
| Max Speed | 6.9 mph |
| Fuel Capacity | 84.6 gal |
| Breakout Force Bucket | 39,791 lb |
| Cooling System Fluid Capacity | 15.4 gal |
| Hydraulic System Fluid Capacity | 46.3 gal |
| Final Drive Fluid Capacity - each | 4.5 gal |
| Engine Oil Capacity | 5.9 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 55 A |
Engine
| Engine Model | D 926 Tl-E |
|---|---|
| Power Measured @ | 1,800 rpm |
| Net Power | 180.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbo-charged |
Hydraulic System
| Pump Flow Capacity | 55.3 gal/min |
|---|---|
| Relief Valve Pressure | 6,090 psi |
| Pump Type | swash plate piston pump |
Dimensions
| Ground Clearance | 202 in |
|---|---|
| Height - Top of Cab | 131 in |
| Length with Bucket on Ground | 267 in |
| Reach at Dump Height | 47 in |
| Clearance at Full Height and Dump | 217 in |
| Length to Front of Track | 190 in |
Undercarriage
| Track Gauge | 71 in |
|---|---|
| Ground Pressure | 10 psi |
| Number of Track Rollers per Side | 6 |
