D150
Crawler Dozer
40 specifications
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Operating Weight | 30,000 lb |
|---|---|
| Fuel Capacity | 81.9 gal |
| Cooling System Fluid Capacity | 13.8 gal |
| Final Drives Fluid Capacity | 1.5 gal |
| Engine Oil Capacity | 4.8 gal |
| Hydraulic Fluid Capacity | 47.1 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 55 A |
Engine
| Engine Model | D 924 T-E |
|---|---|
| Displacement | 409 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 105.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
Hydraulic System
| Pump Flow Capacity | 30.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,300 psi |
| Pump Type | Load sensing proportional pump flow control |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 122 in |
| Length of Track on Ground | 103 in |
| Width Over Tracks | 109 in |
| Length w/ Blade | 185 in |
| Length w/o Blade | 145 in |
Transmission
| Max Speed - Forward | 6.8 mph |
|---|---|
| Transmission Type | Hydrostatic |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 70 in |
| Number of Track Rollers per Side | 7 |
| Standard Shoe Size | 22 in |
Standard Blade
| Width | 119 in |
|---|---|
| Height | 38 in |
| Capacity | 2.80 yd³ |
