Liebherr
Komatsu
D65PX-17
Crawler Dozer
27 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 119,462 lb |
|---|---|
| Fuel Capacity | 222.0 gal |
| Cooling System Fluid Capacity | 23.8 gal |
| Final Drives Fluid Capacity | 6.8 gal |
| Engine Oil Capacity | 17.2 gal |
| Hydraulic Fluid Capacity | 72.7 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 140 A |
Engine
| Engine Model | D 9508 A7-04 Emission regulations EPA/CARB Tier 4f |
|---|---|
| Displacement | 989 in³ |
| Power Measured @ | 1,600 rpm |
| Net Power | 415.8 hp |
| Aspiration | Turbochanged |
| Cooling system | Hydrostatic fan drive |
Hydraulic System
| Pump Flow Capacity | 93.0 gal/min |
|---|---|
| Pump Type | Swash plate piston pump |
Dimensions
| Ground Clearance | 28 in |
|---|---|
| Height - Top of Cab | 157 in |
| Length of Track on Ground | 141 in |
| Width Over Tracks | 113 in |
| Track Gauge | 89 in |
Transmission
| Max Speed - Reverse | 2.5 mph |
|---|---|
| Transmission Type | Infinitely variable hydrostatic travel drive independent drive for each track |
Undercarriage
| Number of Track Rollers per Side | 7 |
|---|---|
| Number of Carrier Rollers per Side | 2 |
Standard Blade
| Width | 173 in |
|---|---|
| Height | 77 in |
| Capacity | 17.80 yd³ |
