936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
63 data points
Operating Specifications
| Fuel Capacity | 186.3 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 137.4 gal/min |
| Hydraulic System Fluid Capacity | 116.3 gal |
| Hydraulic System Relief Valve Pressure | 5,076 psi |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 55 A |
Engine
| Engine Model | D 926 TI-E |
|---|---|
| Displacement | 610 in³ |
| Power Measured @ | 2,000 rpm |
| Aspiration | Turbo-charged |
Dimensions
| Ground Clearance | 22 in |
|---|---|
| Height - Top of Cab | 126 in |
| Length of Track on Ground | 158 in |
| Tail Swing Radius | 134 in |
| Width to Outside of Tracks | 119 in |
| Removal Counterweight Clearance | 50 in |
| Digging Depth | 324 in |
| Digging Reach | 324 in |
Undercarriage
| Ground Pressure | 12 psi |
|---|---|
| Track Gauge | 95 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.2 mph |
| Shoe Size | 20 in |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 75,536 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 247 in |
|---|---|
| Max Reach Along Ground | 390 in |
| Max Loading Height | 278 in |
| Max Cutting Height | 402 in |
| Shipping Length of Unit | 432 in |
| Shipping Height of Unit | 143 in |
Bucket
| Reference Bucket Capacity | 2.39 yd³ |
|---|---|
| Maximum Bucket Capacity | 3.51 yd³ |
| Minimum Bucket Capacity | 0.80 yd³ |
Swing Mechanism
| Swing Speed | 6 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 267 in |
|---|---|
| Max Cutting Height | 410 in |
| Max Loading Height | 285 in |
| Max Reach Along Ground | 410 in |
| Shipping Length of Unit | 430 in |
| Shipping Height of Unit | 134 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 294 in |
|---|---|
| Max Cutting Height | 424 in |
| Max Loading Height | 300 in |
| Max Reach Along Ground | 433 in |
| Shipping Length of Unit | 432 in |
Boom/Stick Excavator Option 4
| Max Digging Depth | 325 in |
|---|---|
| Max Cutting Height | 442 in |
| Max Reach Along Ground | 466 in |
| Max Loading Height | 316 in |
| Shipping Length of Unit | 433 in |
Boom/Stick Excavator Option 5
| Max Digging Depth | 263 in |
|---|---|
| Max Reach Along Ground | 430 in |
| Max Cutting Height | 497 in |
| Max Loading Height | 369 in |
| Shipping Height of Unit | 132 in |
| Shipping Length of Unit | 469 in |
Boom/Stick Excavator Option 6
| Max Digging Depth | 282 in |
|---|---|
| Max Reach Along Ground | 450 in |
| Max Cutting Height | 512 in |
| Max Loading Height | 384 in |
| Shipping Length of Unit | 469 in |
| Shipping Height of Unit | 137 in |
