936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
62 data points
Operating Specifications
| Fuel Capacity | 277.4 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 216.7 gal/min |
| Hydraulic System Fluid Capacity | 224.6 gal |
| Hydraulic System Relief Valve Pressure | 5,076 psi |
| Operating Voltage | 28 V |
| Alternator Supplied Amperage | 80 A |
Engine
| Engine Model | D 9406 TI-E |
|---|---|
| Displacement | 786 in³ |
| Aspiration | turbocharged |
Dimensions
| Ground Clearance | 24 in |
|---|---|
| Height - Top of Cab | 144 in |
| Length of Track on Ground | 169 in |
| Tail Swing Radius | 165 in |
| Width to Outside of Tracks | 154 in |
| Removal Counterweight Clearance | 49 in |
| Digging Depth | 492 in |
| Digging Reach | 492 in |
Undercarriage
| Ground Pressure | 19 psi |
|---|---|
| Track Gauge | 126 in |
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 2.7 mph |
| Shoe Size | 20 in |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 118,250 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 282 in |
|---|---|
| Max Reach Along Ground | 454 in |
| Max Loading Height | 309 in |
| Max Cutting Height | 459 in |
| Shipping Length of Unit | 497 in |
| Shipping Height of Unit | 152 in |
Bucket
| Reference Bucket Capacity | 4.60 yd³ |
|---|---|
| Maximum Bucket Capacity | 6.91 yd³ |
| Minimum Bucket Capacity | 3.10 yd³ |
Swing Mechanism
| Swing Speed | 6 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 313 in |
|---|---|
| Max Cutting Height | 473 in |
| Max Loading Height | 324 in |
| Max Reach Along Ground | 482 in |
| Shipping Length of Unit | 497 in |
| Shipping Height of Unit | 152 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 346 in |
|---|---|
| Max Cutting Height | 487 in |
| Max Loading Height | 337 in |
| Max Reach Along Ground | 512 in |
| Shipping Length of Unit | 499 in |
Boom/Stick Excavator Option 4
| Max Digging Depth | 325 in |
|---|---|
| Max Cutting Height | 494 in |
| Max Reach Along Ground | 503 in |
| Max Loading Height | 346 in |
| Shipping Length of Unit | 546 in |
Boom/Stick Excavator Option 5
| Max Digging Depth | 356 in |
|---|---|
| Max Reach Along Ground | 531 in |
| Max Cutting Height | 509 in |
| Max Loading Height | 359 in |
| Shipping Height of Unit | 156 in |
| Shipping Length of Unit | 548 in |
Boom/Stick Excavator Option 6
| Max Digging Depth | 389 in |
|---|---|
| Max Reach Along Ground | 561 in |
| Max Cutting Height | 522 in |
| Max Loading Height | 373 in |
| Shipping Length of Unit | 550 in |
| Shipping Height of Unit | 159 in |
