Lift King
Caterpillar
GC70K
Forklift
27 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Operating Weight | 29,800 lb |
|---|---|
| Tire Size | 14.00-24 |
| Operating Voltage | 12 V |
Engine
| Engine Model | Cummins 4A3.9 |
|---|---|
| Gross Power | 116.0 hp |
| Aspiration | turbocharged |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Wheelbase | 119 in |
| Width Over Tires | 95 in |
| Overall Height | 100 in |
| Length to Fork Face | 257 in |
| Turning Radius Outside Tires | 181 in |
Transmission
| Transmission Type | Clark-Hurth Components 3 speed powershift |
|---|---|
| Number of Forward Gears | 3 |
Lift System
| Max Lift Capacity | 10,000 lb |
|---|---|
| Max Lift Height | 639 in |
| Max Forward Reach | 445 in |
| Max Load at Max Height | 3,000 lb |
| Max Load at Max Reach | 1,500 lb |
