Link Belt
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
44 data points
Operating Specifications
| Fuel Capacity | 26.5 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 37.8 gal/min |
| Hydraulic System Fluid Capacity | 25.1 gal |
| Hydraulic System Relief Valve Pressure | 4,260 psi |
| Engine Oil Capacity | 2.6 gal |
| Cooling System Fluid Capacity | 2.6 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | CC-4JG1 |
|---|---|
| Displacement | 187 in³ |
| Power Measured @ | 2,100 rpm |
| Number of Cylinders | 4 |
| Aspiration | Natural |
| Torque Measured @ | 1,800 rpm |
| Max Torque | 136 lb-ft |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 107 in |
| Width to Outside of Tracks | 93 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Track Gauge | 74 in |
| Number of Track Rollers per Side | 5 |
| Max Travel Speed | 3.0 mph |
| Shoe Size | 18 in |
| Number of Shoes per Side | 39 |
| Number of Carrier Rollers per Side | 1 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 166 in |
|---|---|
| Max Reach Along Ground | 272 in |
| Max Loading Height | 174 in |
| Max Vertical Wall Digging Depth | 122 in |
| Max Cutting Height | 252 in |
| Shipping Length of Unit | 261 in |
| Shipping Height of Unit | 107 in |
Bucket
| Reference Bucket Capacity | 0.41 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.50 yd³ |
| Minimum Bucket Capacity | 0.30 yd³ |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|---|
| Swing Torque | 12,520 lb-ft |
Boom/Stick Excavator Option 2
| Max Digging Depth | 181 in |
|---|---|
| Max Vertical Wall Digging Depth | 141 in |
| Max Cutting Height | 260 in |
| Max Loading Height | 181 in |
| Max Reach Along Ground | 287 in |
| Shipping Length of Unit | 265 in |
| Shipping Height of Unit | 107 in |
