LiugongZettelmeyer
ZL5001
Wheel Loader
35 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 62,832 lb |
|---|---|
| Fuel Capacity | 117.6 gal |
| Tire Size | 29.5-25 |
| Hydraulic System Fluid Capacity | 66.1 gal |
Engine
| Engine Model | M11-C310 |
|---|---|
| Displacement | 659 in³ |
| Power Measured @ | 2,100 rpm |
| Net Power | 310.0 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,300 rpm |
Hydraulic System
| Raise Time | 6.3 s |
|---|---|
| Lower Time | 3.8 s |
| Dump Time | 1.5 s |
| Relief Valve Setting | 3,002 psi |
| Pump Type | Gear |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 152 in |
| Wheelbase | 139 in |
| Width Over Tires | 126 in |
| Reach at Max Lift and Dump | 60 in |
| Length with Bucket on Ground | 369 in |
| Hinge Pin - Max Height | 176 in |
Transmission
| Max Speed - Forward | 21.8 mph |
|---|---|
| Max Speed - Reverse | 15.3 mph |
| Transmission Type | Powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 5.90 yd³ |
|---|---|
| Dump Clearance at Max Raise | 131 in |
| Breakout Force | 58,450 lb |
| Bucket Width | 137 in |
