Liugong
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Operating Weight | 37,479 lb |
|---|---|
| Tire Size | 23.5-25 |
Engine
| Engine Model | WD61567G3-36A |
|---|---|
| Power Measured @ | 2,200 rpm |
| Net Power | 211.9 hp |
Hydraulic System
| Pump Type | Gear |
|---|
Dimensions
| Height - Top of Cab | 134 in |
|---|---|
| Width Over Tires | 118 in |
| Reach at Max Lift and Dump | 48 in |
| Length with Bucket on Ground | 317 in |
Transmission
| Max Speed - Forward | 23.7 mph |
|---|---|
| Max Speed - Reverse | 15.0 mph |
| Transmission Type | Powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 4.00 yd³ |
|---|---|
| Dump Clearance at Max Raise | 118 in |
| Breakout Force | 38,218 lb |
