Manitou
Komatsu
FG25T-12
Forklift
32 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight | 9,579 lb |
|---|---|
| Max Speed | 13.7 mph |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | front 28-9-15PR rear 6.5-10-10 PR |
Engine
| Engine Model | H25 |
|---|---|
| Displacement | 151 in³ |
| Power | 48.3 hp |
| Fuel Type | LPG |
Dimensions
| Ground Clearance | 6 in |
|---|---|
| Wheelbase | 67 in |
| Overall Width | 50 in |
| Turning Radius | 93 in |
| Overall Height - mast lowered | 88 in |
| Length to Fork Face | 104 in |
| Height to Top of Overhead Guard | 85 in |
| Max Fork Height | 133 in |
Mast
| Load Capacity | 6,000 lb |
|---|---|
| Load Center | 20 in |
| Mast Tip Forward | 6 ° |
| Mast Tip Rear | 12 ° |
| Max Fork Spread | 50 in |
