MecMec
2591ES
Aerial Lift
22 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Engine
| System Voltage | 48 V |
|---|---|
| Battery Amp Hours | 375 |
| Number of Batteries | 8 |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Wheelbase | 103 in |
| Overall Length | 12 in |
| Overall Width | 91 in |
| Turning Radius | 196 in |
| Height w/ Rails | 119 in |
| Height w/o Rails | 88 in |
Performance
| Operating Weight | 10,296 lb |
|---|---|
| Max Speed | 2.7 mph |
| Tire Size | 12-16.5 NHS ""outrigger"""NULL |
| Hydraulic System Fluid Capacity | 23.0 gal |
Platform
| Max Platform Height | 493 in |
|---|---|
| Max Platform Weight Capacity | 1,001 lb |
| Platform Inner Length | 132 in |
| Max Working Height | 571 in |
| Lift Time | 45.0 s |
| Deck Extension | 48 in |
| Lower Time | 52.0 s |
| Height of Rails | 46 in |
