Michigan
L150
- Operating Weight
- 46,870 lb
- Bucket Capacity - heaped
- 8.59 yd³
- Gross Power
- 245.0 hp
- Net Power
- 231.0 hp
1 / 5
Image 1 of 5
Specifications
45 data points
Operating Specifications
| Operating Weight | 46,870 lb |
|---|---|
| Fuel Capacity | 89.6 gal |
| Tire Size | 26.5-R25 |
| Hydraulic System Fluid Capacity | 64.8 gal |
| Static Tipping Weight | 32,760 lb |
| Operating Voltage | 24 V |
| Turning Radius | 292 in |
| Engine Oil Fluid Capacity | 7.7 gal |
| Rear Axle Oscillation | 15 ° |
| Alternator Supplied Amperage | 60 A |
| Front Axle/Diff Fluid Capacity | 12.2 gal |
| Rear Axle/Diff Fluid Capacity | 12.2 gal |
| Cooling System Fluid Capacity | 17.2 gal |
| Transmission Fluid Capacity | 11.9 gal |
Engine
| Engine Model | TD 102 GC |
|---|---|
| Displacement | 586 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 245.0 hp |
| Net Power | 231.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,200 rpm |
Hydraulic System
| Pump Flow Capacity | 82.8 gal/min |
|---|---|
| Raise Time | 6.7 s |
| Lower Time | 3.2 s |
| Dump Time | 1.9 s |
| Relief Valve Setting | 3,046 psi |
| Pump Type | vane pump |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 144 in |
| Wheelbase | 141 in |
| Width Over Tires | 118 in |
| Reach at Max Lift and Dump | 48 in |
| Length with Bucket on Ground | 324 in |
| Hinge Pin - Max Height | 172 in |
Transmission
| Max Speed - Forward | 21.1 mph |
|---|---|
| Max Speed - Reverse | 14.5 mph |
| Transmission Type | Volvo BM HT 210 power shift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 8.59 yd³ |
|---|---|
| Bucket Capacity - struck | 4.09 yd³ |
| Dump Clearance at Max Raise | 120 in |
| Breakout Force | 37,320 lb |
| Bucket Width | 126 in |
