Mustang
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 5,600 lb |
|---|---|
| Max Speed | 7.0 mph |
| Fuel Capacity | 14.3 gal |
| Hydraulic System Fluid Capacity | 13.0 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 700 A |
Engine
| Engine Model | 4TNV88 |
|---|---|
| Displacement | 134 in³ |
| Power Measured @ | 3,000 rpm |
| Gross Power | 47.0 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 18.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,500 psi |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 113 in |
| Wheelbase | 37 in |
| Width Over Tires | 65 in |
| Reach at Max Lift and Dump | 88 in |
| Length with Bucket | 124 in |
| Clearance at Max Lift and Dump | 89 in |
| Turning Radius from Center - machine rear | 51 in |
| Length w/o Bucket | 96 in |
Loader
| Bucket Capacity | 0.50 yd³ |
|---|---|
| Operating Load Rating | 1,500 lb |
| Tipping Angle | 2,900 ° |
| Operating Width | 59 in |
| Breakout Force | 4,000 psi |
