Mustang
Caterpillar
305.5E CR
Mini Excavator
4 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 12,566 lb |
|---|---|
| Hydraulic Pump Flow Capacity | 49.5 gal/min |
| Hydraulic System Relief Valve Pressure | 3,553 psi |
Engine
| Engine Model | 4TNV98-VNS |
|---|---|
| Displacement | 203 in³ |
| Gross Power | 69.0 hp |
| Net Power | 57.0 hp |
| Number of Cylinders | 4 |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 102 in |
| Tail Swing Radius | 57 in |
| Width to Outside of Tracks | 78 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Number of Track Rollers per Side | 5 |
| Max Travel Speed | 3.0 mph |
| Shoe Size | 16 in |
| Number of Carrier Rollers per Side | 1 |
| Drawbar Pull | 13,669 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 151 in |
|---|---|
| Max Reach Along Ground | 240 in |
| Max Vertical Wall Digging Depth | 113 in |
| Max Loading Height | 157 in |
| Shipping Length of Unit | 228 in |
| Max Cutting Height | 222 in |
| Shipping Height of Unit | 102 in |
Bucket
| Reference Bucket Capacity | 0.20 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.41 yd³ |
| Minimum Bucket Capacity | 0.10 yd³ |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|---|
| Swing Torque | 8,296 lb-ft |
Boom/Stick Excavator Option 2
| Max Digging Depth | 163 in |
|---|---|
| Max Cutting Height | 230 in |
| Max Loading Height | 166 in |
| Max Vertical Wall Digging Depth | 124 in |
| Max Reach Along Ground | 252 in |
| Shipping Height of Unit | 102 in |
| Shipping Length of Unit | 228 in |
