New Holland
John Deere
8RT 335
Tractor
17 specifications
New Holland
9682
- Operating Weight
- 31,865 lb
- Displacement
- 854 in³
- Power Measured @
- 2,100 rpm
- Gross Power
- 360.0 hp
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Operating Weight | 31,865 lb |
|---|---|
| Fuel Capacity | 245.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 12,999 lb |
| 3 Point Hitch Type | IVN/3 |
| Alternator Supplied Amperage | 130 A |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 31.0 gal |
| Front Tire Size | 20.8R42 |
| Rear Tire Size | 20.8R42 |
Engine
| Engine Model | Cummins N14 |
|---|---|
| Displacement | 854 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 360.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Engine Make | New Holland |
| PTO Power | 320.0 hp |
| Bore | 6 in |
| Stroke | 6 in |
| Torque | 1,215 lb-ft |
Hydraulic System
| Pump Flow Capacity | 31.0 gal/min |
|---|---|
| Number of Remote Control Valves | — |
| Relief Valve Pressure | 2,900 psi |
| Hydraulic System Type | Closed center load sensing |
Dimensions
| Height - Top of Cab | 137 in |
|---|---|
| Wheelbase | 133 in |
| Overall Length | 266 in |
| Overall Width | 150 in |
| Shipping weight | 19,729 lb |
Transmission
| Max Speed - Reverse | 6.1 mph |
|---|---|
| Max Speed - Forward | 17.1 mph |
| Number of Forward Gears | 12 |
| Transmission Type | Partially synchronized |
| Number of Reverse Gears | 4 |
Production
| Series | 9082 Series |
|---|---|
| Years Manufactured | 1,996 – 2,000 |
