New Holland
Kubota
B2920
Tractor
23 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Engine
| Engine Model | Boomer 24-HP |
|---|---|
| Displacement | 79 in³ |
| Gross Power | 24.0 hp |
| Engine Type | 3-cylinder diesel Tier 4 |
| Alternator | 50 A |
| Air cleaner | Single replaceable dry element |
| Rated Speed | 2,700 rpm |
| Fuel tank capacity | 6.7 gal |
Weights
| Weight | 1,708 lb |
|---|---|
| Tire choice | R3 turf tread or R4 industrial tread |
Hydraulic System
| Remote control valves available | Optional DIA |
|---|---|
| Implement hydraulic flow | 6.8 gal/min |
| Steering Type | Hydrostatic |
| 3-point lift capacity @ ball ends | 1,433 lb |
| Steering Pump Flow | 3.0 gal/min |
Dimensions
| Wheelbase | 708 in |
|---|---|
| Overall Length | 104 in |
| Overall Width | 9,300 in |
| Height - Top of ROPS/FOPS | 86 in |
| Tire choice | R3 turf tread or R4 industrial tread |
| Weight (HST) | 1,709 lb |
Transmission
| Max Speed - Forward | 11.3 mph |
|---|---|
| Transmission Type | HST+2 range |
| Brakes | Mechanical/wet multi disc |
| Cruise control | Standard |
| Rear diff. lock engagement | Mechanical/foot |
Production
| Series | Boomer Series |
|---|---|
| Years Manufactured | — |
Power Take-Off (PTO)
| PTO type | Electro-hydraulic engaged; independent |
|---|---|
| PTO speed rear | 540 rpm |
| PTO Speed Mid | 2,000 rpm |
| PTO | Standard rear and mid PTO |
| PTO (HST) | 18.5 hp |
