New Holland
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
38 data points
Operating Specifications
| Fuel Capacity | 111.0 gal |
|---|---|
| Hydraulic System Fluid Capacity | 105.7 gal |
| Engine Oil Capacity | 4.3 gal |
| Cooling System Fluid Capacity | 7.4 gal |
| Swing Drive Fluid Capacity | 1.0 gal |
Engine
| Engine Model | Cummins 6A 5.9C |
|---|---|
| Displacement | 360 in³ |
| Net Power | 176.0 hp |
| Aspiration | Turbocharged |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 119 in |
| Length of Track on Ground | 151 in |
| Tail Swing Radius | 119 in |
| Width to Outside of Tracks | 126 in |
| Removal Counterweight Clearance | 44 in |
Undercarriage
| Number of Track Rollers per Side | 8 |
|---|---|
| Max Travel Speed | 3.2 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 51 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 49,908 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 252 in |
|---|---|
| Max Reach Along Ground | 383 in |
| Max Loading Height | 269 in |
| Max Vertical Wall Digging Depth | 134 in |
| Max Cutting Height | 371 in |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|---|
| Swing Torque | 56,791 lb-ft |
Boom/Stick Excavator Option 2
| Max Digging Depth | 272 in |
|---|---|
| Max Vertical Wall Digging Depth | 119 in |
| Max Cutting Height | 362 in |
| Max Loading Height | 264 in |
| Max Reach Along Ground | 395 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 292 in |
|---|---|
| Max Cutting Height | 374 in |
| Max Loading Height | 270 in |
| Max Vertical Wall Digging Depth | 143 in |
| Max Reach Along Ground | 414 in |
