Komatsu
PC210NLC-7
Excavator
71 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 77,382 lb |
|---|---|
| Fuel Capacity | 158.5 gal |
| Hydraulic Pump Flow Capacity | 150.6 gal/min |
| Hydraulic System Fluid Capacity | 148.0 gal |
| Hydraulic System Relief Valve Pressure | 4,641 psi |
| Engine Oil Capacity | 6.1 gal |
| Cooling System Fluid Capacity | 11.1 gal |
Engine
| Engine Model | 6CTA 8.3 |
|---|---|
| Displacement | 507 in³ |
| Net Power | 249.0 hp |
| Aspiration | Turbo Charged |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 125 in |
| Length of Track on Ground | 159 in |
| Tail Swing Radius | 131 in |
| Width to Outside of Tracks | 134 in |
| Removal Counterweight Clearance | 47 in |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 93 in |
| Shoe Size | 32 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 292 in |
|---|---|
| Max Reach Along Ground | 438 in |
| Max Loading Height | 316 in |
| Max Vertical Wall Digging Depth | 233 in |
| Max Cutting Height | 430 in |
| Shipping Length of Unit | 445 in |
| Shipping Height of Unit | 137 in |
Bucket
| Reference Bucket Capacity | 1.80 yd³ |
|---|
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
