New Holland
Case
440
Skid Steer Loader
32 specifications
.jpg)
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Operating Weight | 7,385 lb |
|---|---|
| Max Speed | 11.9 mph |
| Fuel Capacity | 25.5 gal |
| Hydraulic System Fluid Capacity | 6.1 gal |
| Tire Size | 12x 16.5 |
| Engine Oil Fluid Capacity | 2.6 gal |
| Shipping Weight - Empty | 7,055 lb |
Engine
| Engine Model | F5C E9454 |
|---|---|
| Displacement | 195 in³ |
| Power Measured @ | 2,500 rpm |
| Number of Cylinders | 4 |
| Aspiration | Turbo |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 203 lb-ft |
| Engine Make | FPT |
Hydraulic System
| Displacement-Standard aux | 2 in³ |
|---|---|
| Displacement-High-flow aux | 1 in³ |
| Pump Flow Capacity | 22.5 gal/min |
| Relief Valve Pressure | 3,000 psi |
| Pump Type | Gear |
| Dump Time | 2.7 s |
| Lower Time | 2.5 s |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Wheelbase | 53 in |
| Overall Width | 70 in |
| Width Over Tires | 57 in |
| Reach at Max Lift and Dump | 32 in |
| Height - Top of ROPS/FOPS | 79 in |
| Dump angle | 55 ° |
| Dump height - fully raised, 45 degrees dump | 123 in |
| Bucket hinge pin fully raised | 129,528 in |
Loader
| Operating Load Rating | 2,250 lb |
|---|---|
| Operating Width | 69 in |
