New Holland
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Operating Weight | 7,099 lb |
|---|---|
| Max Speed | 11.3 mph |
| Fuel Capacity | 18.0 gal |
| Hydraulic System Fluid Capacity | 15.1 gal |
| Tire Size | 10x16.5 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 30 A |
| Engine Oil Fluid Capacity | 2.2 gal |
| Cooling System Fluid Capacity | 4.5 gal |
| Chain Box Fluid Capacity - each side | 2.7 gal |
| Operating Speed | 6.9 mph |
Engine
| Engine Model | 334TM2 |
|---|---|
| Displacement | 208 in³ |
| Power Measured @ | 2,300 rpm |
| Number of Cylinders | 3 |
| Aspiration | Turbocharged |
Hydraulic System
| Pump Flow Capacity | 19.3 gal/min |
|---|---|
| Relief Valve Pressure | 3,000 psi |
| Pump Type | New Holland double acting |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 78 in |
| Wheelbase | 49 in |
| Width Over Tires | 72 in |
| Reach at Max Lift and Dump | 33 in |
| Length with Bucket | 139 in |
| Clearance at Max Lift and Dump | 101 in |
| Turning Radius from Center - inc bucket | 81 in |
| Turning Radius from Center - machine rear | 70 in |
Loader
| Bucket Capacity | 0.71 yd³ |
|---|---|
| Operating Load Rating | 2,478 lb |
| Tipping Angle | 5,000 ° |
| Breakout Force | 7,670 psi |
